Y-tube - Claw legged insect with SS mesh - Stem (L120mm, Ø30mm) | Arms (L80mm, Ø30mm)
The Y-Tube – Claw-Legged Insects with SS Mesh | Stem (L300mm, Ø20mm) | Arms (L150mm, Ø20mm) is a specialized glass apparatus designed for insect behavioral and olfactory studies involving claw-legged species. It features an internal stainless steel (SS) mesh that provides grip, enabling natural movement and reliable odor-choice responses. Here, L denotes length and Ø denotes diameter, defining the airflow path dimensions.
Dimension Explanation Table
| Symbol / Term | Meaning | Value mm (cm) | Description |
|---|---|---|---|
| L (Stem) | Length of main tube | 300 mm (30 cm) | Distance from base inlet to junction where arms split |
| Ø (Stem) | Diameter of main tube | 20 mm (2 cm) | Inner diameter allowing airflow and insect movement |
| L (Arms) | Length of each arm | 150 mm (15 cm) | Distance from junction to each arm outlet |
| Ø (Arms) | Diameter of each arm | 20 mm (2 cm) | Inner diameter of arms for odor stream passage |
Specifications
| Parameter | Specification |
|---|---|
| Product Name | Y-Tube (SS Mesh Type) |
| Stem Length | 300 mm |
| Stem Diameter | 20 mm |
| Arm Length | 150 mm |
| Arm Diameter | 20 mm |
| Internal Feature | Stainless Steel Mesh |
| Material | Borosilicate Glass |
| Design | Y-Shaped |
| Application | Claw-legged insect olfactory studies |
Customize
Product Details
The Y-Tube – Claw-Legged Insects with SS Mesh | Stem (L300mm, Ø20mm) | Arms (L150mm, Ø20mm) is a specialized laboratory instrument developed for entomological research involving insects with clawed or gripping legs. Smooth glass surfaces in standard setups can restrict insect movement, leading to inaccurate behavioral responses. This model addresses that challenge by incorporating an internal stainless steel (SS) mesh, which acts as a walking surface, allowing insects to move naturally and respond accurately during experiments.
Constructed from high-quality borosilicate glass, the Y-tube ensures excellent transparency, durability, and resistance to chemical exposure. The 300 mm stem (Ø20 mm) provides an extended airflow pathway, allowing better stabilization of incoming air, while the two 150 mm arms (Ø20 mm) ensure equal distribution of odor streams.
The SS mesh enhances traction, mobility, and behavioral accuracy, making this model ideal for studies involving ticks, mites, beetles, and other crawling insects. The extended dimensions also support more stable airflow and improved experimental consistency, especially in larger setups.
The design maintains uniform airflow with minimal turbulence, ensuring reproducible results. Its transparent structure allows easy observation, and the ergonomic design enables seamless integration with air compressors, airflow controllers, charcoal filters, and humidifier chambers.
Applications
- Behavioral studies of claw-legged insects
- Tick, mite, and beetle olfactory research
- Odor-choice and repellency assays
- Entomology and vector biology research
- Agricultural pest behavior studies
- Laboratory olfactometer experiments
Specifications
- Stem Diameter20mm
- Stem Height360mm
- Arm Diameter20mm
- Arm Height180mm
- Arm Angle45°
- Connector Diameter6mm
