Almicro Multi-Head Microscope Series - Collaborative Laboratory Solutions
The Alamicro Multi-Head Microscope Series represents a specialized advancement in educational and collaborative microscopy, enabling simultaneous observation by multiple users from a single specimen. These professional instruments transform traditional microscopy training into efficient, interactive learning experiences while supporting collaborative research and diagnostic analysis.
Multi-Head Microscopy Concept
Multi-head microscopes enable 5-10 simultaneous observers to examine identical specimens without time-consuming sequential viewing. This revolutionary approach provides:
- Efficient group learning and comparative analysis
- Real-time collaborative observation and discussion
- Simultaneous demonstration and verification
- Cost-effective institutional microscopy solution
- Enhanced teaching effectiveness and student engagement
- Professional diagnostic verification by multiple specialists
Description
Premium decahead (10-person) microscope engineered for maximum collaborative observation capacity. Features infinity-corrected plan optical system, 1 trinocular main head with 9 supplemental binocular heads inclined at 30°, wide field eyepieces (10x/22mm), quadruple nosepiece, infinity plan objectives (4x, 10x, 40x, 100x), Abbe condenser (N.A. 1.25), coaxial coarse and fine focusing (0.002mm minimum division), double-layer mechanical stage (180mm x 160mm), and halogen illumination (12V/100W) with adjustable brightness and LED cursor pointer.
Key Specifications
- Multi-Head Configuration: 1 Trinocular Main Head + 9 Binocular Supplemental Heads (10 total observers)
- Head Design: Supplemental binocular heads inclined at 30°
- Eyepieces: Wide Field Eyepiece EWF 10x/22mm
- Objectives: Infinity Plan 4x, 10x, 40x, 100x (oil immersion capable)
- Nosepiece: Quadruple with click stops
- Optical System: Infinity-corrected plan optical system providing excellent image quality and image
- Stage: Double layer mechanical stage (180mm x 160mm movement capability)
- Condenser: Abbe Condenser N.A. 1.25
- Focusing System: Coaxial coarse and fine adjustment, fine division 0.002mm
- Illumination: Halogen lamp 12V/100W, adjustable brightness
- Illumination Control: LED cursor pointer with brightness adjustable
- Magnification Range: 40x - 2500x (with oil immersion)
- Certifications: TRINO, 360°, LED, IL, ABBE, 230V, 2 DAY
Ideal Applications
- Medical college pathology teaching with full class observation
- Dental college histology and diagnostic training
- Teaching hospital collaborative diagnostics
- Research institution group analysis sessions
- Large-scale group seminars and demonstrations
- Professional development and specialist training programs
Key Benefits
- Maximum Efficiency: 10 simultaneous observers eliminate time-consuming sequential viewing
- Superior Optics: Infinity-corrected plan system delivers exceptional image quality for all observers
- Professional Precision: 0.002mm fine adjustment enables precise specimen focus
- Institutional Scale: Accommodates entire classroom or research group simultaneously
- Versatile Illumination: LED cursor pointer enables instructor highlighting and annotation
- Cost-Effective: Single instrument serves 10 users, reducing per-student cost dramatically
Description
Professional pentahead (5-person) microscope designed for collaborative group analysis and teaching demonstrations. Features achromatic optical system, 5 binocular heads inclined at 30° with wooden table support for convenient simultaneous viewing, wide field eyepieces (10x/18mm), quadruple nosepiece, achromatic objectives (4x, 10x, 40x, 100x), swing condenser (N.A. 0.9/0.25), coaxial coarse and fine focusing, plain layer mechanical stage (140mm x 140mm), and halogen illumination (6V/30W) with adjustable brightness and LED pointer.
Key Specifications
- Multi-Head Configuration: 5 Binocular Heads for simultaneous observation
- Head Design: Binocular heads inclined at 30°, rotatable around wooden table support
- Eyepieces: Wide Field Eyepiece WF 10x/18mm
- Objectives: Achromatic 4x, 10x, 40x, 100x (oil immersion capable)
- Nosepiece: Quadruple nose piece
- Optical System: Achromatic optics providing very good optical quality
- Stage: Plain layer mechanical stage (140mm x 140mm)
- Condenser: Swing Condenser N.A. 0.9/0.25
- Focusing System: Coaxial coarse and fine adjustment, fine division 0.002mm
- Illumination: Halogen lamp 6V/30W, adjustable brightness
- Illumination Control: LED pointer with brightness adjustable
- Support Structure: Wooden table (convenient group positioning and stability)
- Magnification Range: 40x - 1000x (standard), expandable with oil immersion
- Certifications: TRINO, LED, IL, ABBE, 230V, 2 DAY
Ideal Applications
- Medical college small group pathology demonstrations
- Dental school histology and diagnostic group teaching
- Clinical diagnostic team analysis sessions
- Research group collaborative analysis
- Professional case review and consultation
- Small-scale institutional teaching scenarios
Key Benefits
- Group Efficiency: 5 simultaneous observers enable collaborative learning and discussion
- High-Quality Optics: Achromatic objectives deliver excellent image quality for group viewing
- Flexible Positioning: Wooden table support allows convenient observer positioning
- Institutional Value: Reduces microscope requirements and training time significantly
- Interactive Teaching: LED pointer enables instructor-led annotation and demonstration
- Practical Investment: Cost-effective solution for small to medium group observation needs
| Feature | X-10 Decahead | X-555 Pentahead |
|---|---|---|
| Observer Capacity | 10 simultaneous | 5 simultaneous |
| Main Head | 1 Trinocular | Part of binocular set |
| Supplemental Heads | 9 Binocular @ 30° | 4 additional binocular @ 30° |
| Eyepieces | EWF 10x/22mm | WF 10x/18mm |
| Objectives | Infinity Plan 4x-100x | Achromatic 4x-100x |
| Optical System | Infinity-corrected plan | Achromatic |
| Stage Size | 180x160mm | 140x140mm |
| Condenser | Abbe N.A. 1.25 | Swing N.A. 0.9/0.25 |
| Illumination | Halogen 12V/100W | Halogen 6V/30W |
| Focusing | Fine 0.002mm | Fine 0.002mm |
| Support Structure | Pedestal base | Wooden table |
| Max Magnification | 2500x (oil) | 1000x (standard) |
| Price Category | Premium (10-person) | Professional (5-person) |
| Best For | Large institutional groups | Small to medium groups |
- Enhanced Learning: All students observe identical specimens simultaneously, reducing confusion and improving comprehension
- Real-Time Discussion: Group can discuss observations immediately while viewing the same specimen
- Efficient Training: Significantly reduces training time by eliminating sequential viewing queues
- Improved Retention: Interactive group learning improves knowledge retention and engagement
- Cost Reduction: One multi-head microscope serves 5-10 students, reducing equipment investment
- Diagnostic Consensus: Multiple specialists simultaneously verify diagnoses and discuss findings
- Quality Assurance: Peer review of pathology specimens in real-time
- Knowledge Sharing: Senior professionals can demonstrate and explain findings to team members
- Time Efficiency: Collaborative analysis sessions completed in single observation period
- Documentation: Trinocular ports enable simultaneous imaging while others observe
| Institution | Recommended Model | Use Case |
|---|---|---|
| Large Medical Colleges | X-10 Decahead | Full class pathology demonstrations (50+ students rotational) |
| Dental Colleges | X-10 or X-555 | Histology labs, diagnostic training |
| Teaching Hospitals | X-555 | Pathology team conferences, case reviews |
| Research Institutions | X-10 or X-555 | Collaborative research group analysis |
| Diagnostic Centers | X-555 | Specialist consultation and verification |
| Small Colleges | X-555 | Group practical sessions and demonstrations |
- Multi-head microscope body with specified number of viewing heads
- Eyepieces as per specification (main head + all supplemental heads)
- Complete set of achromatic or plan-achromatic objectives
- Revolving nosepiece (quadruple)
- Mechanical stage with specimen clips
- Professional Abbe or swing condenser
- Halogen illumination system with brightness control
- LED cursor pointer with adjustable brightness
- Power supply/adapter
- Immersion oil (high-grade for 100x oil objectives)
- Dust covers for protection
- User manuals and care instructions for all heads
- Warranty documentation
- Professional packaging
- Support structure (pedestal base for X-10, wooden table for X-555)
- Each binocular head requires independent eyepiece cleaning and maintenance
- Ensure all heads move smoothly without friction or binding
- Check alignment of all heads periodically to ensure consistent image quality
- Maintain consistent focus across all heads using coaxial adjustment
- Regular cleaning of all eyepieces to prevent dust accumulation
- Professional calibration recommended annually for multi-head alignment
- Use only approved lens cleaning solutions on optical surfaces
- Never use abrasive materials on coated objectives
- Remove immersion oil immediately after use
- Store in dust-free, climate-controlled environment
- Maintain 18-25°C laboratory temperature for optimal performance
- Keep relative humidity at 40-70% to prevent fungal growth
