Storage Air compressor with Pressure Regulator for Insect Olfactometer
Air Compressor – 8 Litre, Oil-Free
A compact, low-noise oil-free air compressor designed for supplying compressed air to pneumatic tools and equipment. Featuring a 0.8 HP copper-winding motor and an 8-litre air storage tank, it delivers reliable airflow for light-duty pneumatic applications. Its direct-drive design offers low vibration, reduced maintenance, and convenient portability.
Technical Specifications
| Specification | Details |
|---|---|
| Product Type | Oil-Free Air Compressor |
| Motor Power | 0.8 HP |
| Motor Speed | 1400 RPM |
| Motor Winding | Copper |
| Tank Capacity | 8 Litres |
| Maximum Working Pressure | 8 Bar |
| Air Delivery at 8 Bar | 1.41 CFM |
| Air Delivery at 4 Bar | 2.30 CFM |
| Noise Level | 68 dB |
| Lubrication | Oil-Free |
| Drive Type | Direct Drive |
| Net Weight | Approx. 12 kg |
| Portability | Compact body with carry handle |
Key Features
Low-noise operation for indoor and workshop environments.
Oil-free design for cleaner air delivery and reduced maintenance.
Copper-winding motor for reliable operation.
Compact and portable construction.
Built-in safety protection mechanisms.
Customize
Product Details
Air Compressor – 8 Litre, Oil-Free
The 8 Litre Oil-Free Air Compressor is a compact and efficient compressed air supply unit designed for operating pneumatic tools and equipment. Equipped with a 0.8 HP copper-winding motor and an 8-litre air storage tank, this compressor provides a convenient air supply for light-duty industrial, laboratory, workshop, and general-purpose applications.
Its oil-free pumping mechanism eliminates the need for regular oil lubrication, helping reduce maintenance requirements and preventing oil contamination associated with conventional lubricated compressors.
Key Features
Compact Air Storage: 8-litre tank provides convenient compressed air storage for intermittent pneumatic applications.
Oil-Free Operation: No regular oil lubrication required, reducing maintenance requirements.
Low-Noise Performance: Operating noise level of approximately 68 dB.
Copper-Winding Motor: Designed for reliable and efficient motor performance.
Direct-Drive Mechanism: Provides a compact construction with reduced mechanical complexity.
Portable Design: Lightweight construction with an integrated carrying handle.
Safety Protection: Equipped with protective mechanisms including overheat protection, overload protection, safety valve, and solenoid valve.
Technical Specifications
| Parameter | Specification |
|---|---|
| Compressor Type | Oil-Free |
| Motor Power | 0.8 HP |
| Motor Speed | 1400 RPM |
| Motor Winding | Copper |
| Air Tank Capacity | 8 Litres |
| Maximum Pressure | 8 Bar |
| Air Delivery at 8 Bar | 1.41 CFM |
| Air Delivery at 4 Bar | 2.30 CFM |
| Noise Level | 68 dB |
| Drive Mechanism | Direct Drive |
| Lubrication | Oil-Free |
| Approximate Weight | 12 kg |
Applications
Operating pneumatic laboratory equipment.
Supplying compressed air to small pneumatic tools.
Airbrush and spray applications.
Pneumatic stapling and fastening operations.
Workshop and maintenance activities.
General-purpose compressed air requirements.
Advantages
The compact design, low operating noise, and oil-free pumping system make this compressor suitable for applications where portability and reduced maintenance are important. Its 8-litre tank provides a convenient compressed air reserve for intermittent operations and light-duty pneumatic equipment.
Note: The suitability of the compressor depends on the air consumption and operating pressure requirements of the connected equipment. Continuous-duty applications should be evaluated against the compressor's rated air delivery.
